Features
Uncompromising Security, Day or Night, Rain or Shine
See it all, hear it all. Lorex A4 cameras offer crystal-clear video, audio recording, smart motion detection, and IP67 weatherproof ratings for complete security.
Resolution
Color Night
Vision
IK10
Vandal Proof
IP67
Weatherproof
Built-in
Microphone
Person and Vehicle
Detection
Sharp Details, Sharp Security
2K resolution captures detailed footage for undeniable evidence.
Night Vision Evolved: Capture Every Detail in Color
Don’t miss a thing with Lorex’s Color Night Vision (CNV) in low light conditions or crisp black and white footage in total darkness.
Vandal Proof Metal Camera
An IK10 vandal proof rating ensures protection from strong impacts, making them perfect for within-reach indoor and outdoor installations.
All-Season Security
Heavy-duty aluminum exteriors and IP67 weatherproof rated designs guarantee extreme temperature (-40°F to +140°) and weather durability.
Hear the Whole Story
A built-in microphone captures audio for an extra layer of evidence.
Smart Motion Detection (Person and Vehicle)
Person and vehicle detection helps identify and categorize motion events, and limit unnecessary alerts caused by other moving objects.
Wired Reliability
Connect A4 cameras to a compatible NVR for a stable camera connection, 24/7 continuous recording and the ability to record without internet.
Product Compatibility
Product Specifications
| Image Sensor | 4MP CMOS |
| Video Format | NTSC |
| Video Compression | H.265/H264 (Main Stream & Sub Stream) |
| Video Streams | 2 (Mainstream & Substream) |
| Viewing Angle (diaognal) | 125° |
| Lens/Lens type | 2.8mm F1.6/Fixed |
| Resolution/Frame rate | 4MP (2688 × 1520/2560 × 1440); 3MP (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate (Maximum) | Mainstream: 2688 × 1520@(1–20 fps) 2560 × 1440@(1–25/30 fps) Substream: 704 × 576@(1–25 fps) 704 × 480@(1–30 fps) |
| WDR | Yes |
| Termination | RJ45 |
| Aspect Ratio | 16:9 |
| Microphone | Yes |
| Siren | No |
| Two-way Talk | No |
| Night Vision Range | 98ft (30m) |
| Color Night Vision | Yes |
| Smart Motion Detection | Yes |
| Detection Types | Vehicle and Person |
| Camera Housing Material | Alluminum Alloy |
| Power Requirements | PoE (Power over Ethernet Class -802.3af) / 12V DC |
| Power Consumption (max) | 5.1W (POE), and 4.2W (DC12V) |
| Camera Dimensions (D x H) | 3.1 x 4.3” 81 x 109mm |
| Camera Weight | 1.06lbs / 0.48kg |
| Operating Temperature | -40°F (-40°C) ~ +140°F (+60°C) |
| Humidity | ≤95% |
| Environmental Rating | IP67 |
| Certification | FCC, CE |
What's Included?
- Dome Cover
- Dome Cover Screw (3×)
- Camera Lens
- IR (Infrared) Light (3×)
- Camera Base
- Cable Notch
- Adjustment Screw (2×)
- Microphone
- Reset Button
- MicroSD Card Slot*
- Ethernet Connector
- 12V DC Power Connector
Package Contents:
4MP IP PoE Wired Dome Camera
Mounting Kit
T10 Torx Key
Weather-resistant Cap
*A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing
Product Support
A4 4MP IP Wired Dome Security Camera
